FITTINGS & TUBINGS


Fittings

For 1/4''-28 coned port
VLA-E01-10      1/4''-28 fitting for 1/16'' tubing; 10 / package
VLA-F01-10      1/4''-28 fitting for 2mm tubing; 10 / package
VLA-A03-10     1/4''-28 fitting for 2,6mm tubing; 10 / package
VLA-A04-10
    1/4''-28 fitting for 3mm tubing; 10 / package
VLA-A01-10      1/4''-28 fitting for 1/8'' tubing; 10 / package
For 5/16''-24 coned port
VLA-C01-10      5/16''-24 fitting for 3/16'' tubing; 10 / package
VLA-D01-10      5/16''-24 fitting for 4mm tubing; 10 / package
For M10x1 coned prt
VLA-B01-10      M10x1 fitting for 1/4'' tubing; 10 / package
For M16x1 coned port
VLA-I01
            M16x1 fitting for 1/2'' tubing

Blind Plugs

VLA-A02-10       Blind plug for 1/4''-28 port; 10 / package
VLA-C02-10       Blind plug for 5/16''-24  port; 10 / package
VLA-B02-10       Blind plug for M10x1 port; 10 / package
VLA-I02             Blind plug for M16x1 port

Connectors for Tubings

For 5-8mm O.D. tubings
VLV-B01-10        Barbed connector for 7-8mm ID tubing 10 / package
VLV-B02-10
Barbed connector for 5-8mm ID tubing 10 / package
VLV-B03-10       ESD Barbed connector for 5-8mm ID tubing 10 / package
VLV-Y01-10        Equal Y push-on connector for 7-8mm ID tubings 10 / package
VLV-I01-10         Straight push-on connector for 7-8mm ID tubings 10 / package
VLV-T01-10        Equal T push-on connector for 7-8mm ID tubings 10 / package
For 3-6mm O.D. tubings
VLV-B04-10      Barbed connector for 3-4mm ID tubing 10 / package
VLV-I02-10       Straight push-on connector for 5-6mm ID tubings 10 / package
VLV-T01-10       Equal T push-on connector for 7-8mm ID tubings 10 / package
VLV-Y02-10      Equal Y push-on connector for 5-6mm ID tubings 10 / package
VLV-X02-10     Cross push-on connector for 5-6mm ID tubings 10 / package
Reducing connectors
VLV-I03-10      Reducing straight push-on connector 8mm ID to 6mm ID 10 / package
VLV-T03-10    Reducing T push-on connector 8mm ID to 6mm ID 10 / package
VLV-Y03-10    Reducing T push-on connector 8mm ID to 6mm ID 10 / package

High Pressure Fittings

Flat bottom fittings
VLA-G01-10     1/4''-28 flangeless flat bottom fitting and ferrul for 1/8'' tubings 10 / package
VLA-G02-10    1/8'' flangeless ferrul for 1/4''-28 flat bottom fitting (POM) 10 / package
VLA-G03-10    1/8'' flangeless ferrul for 1/4''-28 flat bottom fitting (PTFE) 10 / package
High pressure fittings
VLA-H01-10     10-32 high pressure fitting for 1/16'' tubing 10 / package
VLA-H02-10    10-32 long high pressure fitting for 1/16'' tubing 10 / package
VLA-H03-10    5/16''-24 high pressure fitting for 1/8'' tubing 10 / package
VLA-H04-10    5/16''-24 high pressure fitting for 1/16'' tubing 10 / package
VLA-H05        High pressure T connector for 3x10-32 port, without fittings Ea
VLA-Z01          ZDV for 1/16" tubings Ea
VLA-Z02         ZDV for 1/8" tubings Ea

Tubings

VLZ-P01           PTFE Capillary 1/32'' (0,8mm) ID, 1/16'' (1,6mm) OD; 1m
VLZ-P02          PTFE Capillary 1/16'' (1,6mm) ID, 1/8'' (3,2mm) OD; 1m
VLZ-P03          PTFE Capillary 1/8'' (3,2mm) ID, 3/16'' (4,8mm) OD; 1m
VLZ-P04          PTFE Capillary 3/16'' (4,8mm) ID, 1/4'' (6,3mm) OD; 1m
VLZ-P05          PTFE Capillary 1,0mm ID, 2,0mm OD; 1m
VLZ-P06          PTFE Capillary 3,0mm ID, 4,0mm OD; 1m
VLZ-S05          Silicon Capillary 1,0mm ID, 2,0mm OD; 1m
VLZ-S07          Silicon Capillary 2,0mm ID, 4,0mm OD; 1m
VLZ-S08          Silicon Tube 7,0mm ID, 10,0mm OD; 1m
VLZ-S09          Silicon Tube 7,0mm ID, 12,0mm OD; 1m
